Aluminium Tilt And Turn Windows
Created with Pixso. Energy Saving Thermal Insulation Aluminium Tilt And Turn Windows Multi Functions

Energy Saving Thermal Insulation Aluminium Tilt And Turn Windows Multi Functions

Brand Name: WEINAS
Model Number: Opatinil 90
MOQ: 2 Square Meters
Price: USD125-140 Per Square Meter
Delivery Time: 25-35 Days
Payment Terms: T/T
Detail Information
Place of Origin:
Foshan, China
Certification:
AS2047
Name:
Multi Functions Tilt And Turn Window
Material:
Aluminium Alloy 6063-T5, Glass
Profile Thickness:
1.8mm
Glass:
5mm+20A+5mm, 5mm+25A+5mm, 5mm+12A+5mm+12A+5mm
Glass Leaf:
Frame Width 88mm
Screen Leaf:
Frame Width 88mm
Wall Occupied:
90mm
Screen Material:
Stainless Steel 304
Open Type:
Tilt And Turn, Swing And Other Modes
Color:
Glossy Grey, Matt Black, Brown
Packaging Details:
Foam, Poly Bag, Wooden Case
Supply Ability:
2000 Square Meters Per Month
Highlight:

thermal insulation aluminium tilt and turn windows

,

energy saving aluminum tilt and turn windows

,

energy saving aluminium tilt and turn windows

Product Description



Multi Functions Energy Saving Thermal Insulation Aluminium Tilt And Turn Window



Product Description:

Tilt and turn window is one kind of casement window. Tilt and turn include 2 opening modes. The first one is inward swing. Just like the traditional casement window, the entire sash opens inwards. This allows for maximum ventilation and convenient for cleaning of the outside of the window. The other one is inward tilt. The top of the sash opens inwards at an angle (usually around 10-15 degrees), while the bottom remains stationary. This is its most distinctive feature.

There are 2 main advantages of tilt and turn window: Rainproof, the opening is located at the top of the sash, making it difficult for rain to enter the room, and ventilation is maintained even when it rains. Air enters from the bottom and exits from the top, forming a gentle convection. Safety: Prevents children from climbing out of the window. Making it particularly suitable to families with children and high-rise apartments. The opening is extremely small. Thieves are difficult to reach in from outside to open the window or operate the handle.



Specifications

Product Name:

Multi Functions Energy Saving Thermal Insulation Aluminium Tilt And Turn Window
Brand: WEINAS
Model: Opatinil 90
Material: Aluminium Alloy 6063-T5, Glass
Profile Thickness: 1.8mm
Glass: 5mm+20A+5mm, 5mm+25A+5mm, 5mm+12A+5mm+12A+5mm
Glass Leaf: Frame Width 88mm
Screen Leaf: Frame Width 88mm
Wall Occupied: 90mm
Color: Glossy Grey, Matt Black, Brown
Open Mode: Swing, Tilt And Turn
Advantages: Ventilated, Safe



Features:

  1. Double inward swing. Glass leaf and screen leaf all can inward swing. Supply one more safety assurance.
  2. Ribbed insulation strips. Different from conventional insulation strips, ribbed strip has a better performance of interfering heat convection and heat conduction.
  3. German brand non base handle. High quality and good looking. Suitable to high grade interior decoration.
  4. Multi soft material sealing system. Ultra low volume when open and close. Supply a quiet interior environment.
  5. Vertical isotherm design thermal insulation system. All insulation strips, sealing strips and insulation glass are all on the same vertical line. Break the transfer and convection of heat.
