Aluminium Casement Windows
Created with Pixso. Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window

Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window

Brand Name: Weinas
Model Number: Weipin 120
MOQ: 2
Price: Rp 2.147.228-2.404.895
Detail Information
Place of Origin:
Guangdong, China
Type:
1
Frame Material:
Aluminum Alloy
Opening Pattern:
Horizontal
Screen Netting Material:
Stainless Steel
Glass Type:
Double Tempered Glass, Low-E Glass, Tinted Glass
Warranty:
More Than 5 Years
Material:
Aluminum, Aluminium 6063-T5, Tempered Insulated Glass
Feature:
Magnetic Screen, Folding Screen
Installation:
Easy To Operate
Open Style:
Swing
Function:
Windproof
After-sale Service:
Online Technical Support
Project Solution Capability:
Graphic Design, 3D Model Design
Application:
Bedroom, Exterior, Dining, Living Room, Apartment, Villa, Hotel, Hospital
Design Style:
Modern
Curtain Type:
Louver
Aluminum Profile:
Aluminium Alloy 6063-T5
Energy Star Qualified:
No
Product Name:
Thermal Insulated Aluminium Exterior Tilt And Turn Casement Window
Profile Thickness:
2mm
Glass:
Double Insulated Glass 5mm+20A+5mm
Glass Leaf:
72mm(Frame Width), 58mm(Leaf Thickness)
Screen Leaf:
60mm(Frame Width), 32mm(Leaf Thickness)
Wall Occupied:
120mm
Color:
Grey, Black, Brown
Open Type:
Tilt And Turn
Advantages:
Heat Insulated, Interior Temperature Stabilized
Highlight:

thermal insulated aluminium casement window

,

airtight tilt and turn window

,

exterior aluminium casement window

Product Description

Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 0



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 2



Product Name:

Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window
Model: WEIPIN 120
Material: Aluminium 6063-T5, Tempered Insulated Glass
Profile Thickness: 2mm
Glass: Double Insulated Glass 5mm+20A+5mm
Glass Leaf: 72mm(Frame Width), 58mm(Leaf Thickness)
Screen Leaf: 60mm(Frame Width), 32mm(Leaf Thickness)
Wall Occupied: 120mm
Color: Grey, Black, Brown
Open Mode: Inward Swing, Inward Tilt
Advantages: Heat Insulated, Interior Temperature Stabilized



Product Description:

Thermal insulated airtight aluminium exterior tilt and turn window offers a combination of the inherent benefits of both thermal break technology and the tilt-and-turn window design. This makes them a highly versatile and energy-efficient choice for both residential and commercial buildings.



Here are the key advantages:



Superior Energy Efficiency:

  1. Thermal Break Technology: Aluminum is a highly conductive material, meaning it easily transfers heat and cold. A "thermal break" is a non-metal material (often a reinforced polyamide bar) placed between the inner and outer aluminum frames. This creates an insulated barrier that significantly reduces the transfer of thermal energy.
  2. Reduced Heat Loss/Gain: In winter, the thermal break prevents heat from escaping through the window frame, keeping your home warmer. In summer, it prevents external heat from entering, keeping your space cooler.
  3. Lower Energy Bills: By minimizing the need for heating and cooling systems, these windows can lead to a significant reduction in energy consumption and lower utility costs.

Versatile Ventilation:

  1. Tilt Function: When the handle is turned vertically, the window tilts inward at the top, creating a secure opening for controlled, gentle airflow. This allows for continuous ventilation without the security risk of a fully open window.
  2. Turn Function: When the handle is turned horizontally, the window swings open inward like a casement window. This provides a large opening for maximum ventilation and is ideal for quickly airing out a room.

Durability and Low Maintenance:

  1. Exceptional Strength: Aluminum is a robust and durable material with an excellent strength-to-weight ratio. It is resistant to warping, swelling, and corrosion.
  2. Long Lifespan: The inherent strength and resistance to external elements mean these windows have a long lifespan, often exceeding 20 years, with minimal wear and tear.
  3. Low Maintenance: Unlike wood, aluminum frames do not require painting or extensive upkeep to maintain their appearance and integrity. They are resistant to rust and do not rot.



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 4



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 6



Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 8



Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 10



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 12



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 14



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 16



 Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 18



Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 20





Certificates:

Our products are all finished doing quality test before shipping out. To supply a better quality assurance, our product are also finished testing of AS2047.

Thermal Insulated Airtight Aluminium Exterior Tilt and Turn Casement Window 22



About WEINAS:

Foshan Weinas Doors And Windows Co., Ltd. Located in Foshan, a major doors and windows manufacturing center in China. We are a modern window and door company integrate development, design, production, sales, and installation services. We specialize in providing high quality, high performance window and door system solutions for residential, commercial, and high-end projects. Main products are aluminium casement windows, sliding windows, sliding doors and casement doors. We know that doors and windows are the eyes of a building and the key of protecting home safety and comfort. We regard quality as the lifeline of the enterprise.
